Name
|
TP1(TC11) | Type
|
TP1(TC11) |
| Technical data | |||
| > Rated capacity(could do according to user’s requirement) Direct current:0.25A/6V、0.25A/12V、0.25A/42V 、0.15A/42V、 0.1A/60V Alternating Current:5.7A/110V、2.8A/220V、2.5A/250V 1.6A/380V、 1.3A/500V >Sensibility load:(COSФ=0.6)3.6A/110V、1.7A/220V 1.6A/250V、1.1A/380V、0.8A/500V > Operation temperature range: 60℃-160℃℃ with 5℃ as a grade > Temperature tolerance: 士5K、士8K、10K >Electric intensity of normality:AC1500V,50/60Hz,lasted 1min,no punching or shining > Insulation resistance: >100 MΩ >Internal resistance: ≤50 MΩ >Cut insulation resistance: >2MΩ |
|||
