| Technical data | |||
| Technical Specification: >Adopt high quality transducer part production technic. >The product with advanced precise temperature-pressure-runoff synthesis testing. >Advanced and high-efficiency sensing medium. >The product can burden overtemperature and overpressure in unusual condition >Advanced full and pour technics and rigotous science testing method >The valve is made of copper forging,Plating nickel after production with higher machanism intensity and antirust function. >Controlling temperature component have a good interchange for all kinds of valve in our factory. >Each testing method accord with EN215 standard and provide the high quality product to the customer. >Temperature control range: 6°C- 28 °C >Water supply temperature:Below 120°C >Working pressure: 1≤MPa >front-back allowable pressure tolerance: ≤1bar >Tube diameter: ND15 / DN20 / ND25 >Valve with copper forging plating nickel >Hydraulic pressure: 1.6MPa >Mechanism life and temperaure resistance: 5000 times >Hot water requirement: pH4.0 - 9.5 >Other technology accord with Europe EN215 standard. The product have already adjusted each scale’s temperature range before delivery,the user only need to choose different scale according to your temperature requirement. • Each temperature adjust range |
|||
